Label Stock Slitting Rewinding Machine

SLD-61510 Self-adhesive Label Slitting Rewinding Machine

Function: suitable for slitting rewinding self-adhesive sticker

paper, etc.

Spec:

1. Material width: Effective width: 1300mm

2. Slitting width: Min. 30mm

3. Rewind core spec.: φ76.2±0.2MM

    Rewind core type: ABS core & PE core & paper core

4. Unwind core spec.: φ76.2±0.2MM φ152.4±0.2MM

    Unwind core type: ABS core & PE core & paper core

5. Unwind diameter: MAXφ1000mm

6. Rewind diameter: MAX φ600mm (top & bottom shaft)

7. Machine speed: 0-300M/min

8. Power source: 380V 50HZ 3P

9. Air source: 5KG (prepared by user)
