TBP-650
FURIMACH
Metal Foil Both-sided Coating Machine for Electronic Products Application
Features:
1. Siemens PLC control system for the whole machine, HMI equipped at each key unit like unwinder, rewinder, coating unit. High degree of automation, easy operation, less manpower.
2. Safety protection devices, emergency stop system and fault alarm function, safer coating production.
3. Independent and precise temperature control for oven partitioned area. 100mm insulation layer inside of oven is more energy-saving.
4. Segmented and closed loop tension control for the whole machine ensures more stable tension, with servo correction/web guide, the rewinding effect is more perfect/orderly.
5. Technical engineering team supports on-site and remote service, from on-site installation & commissioning to common trouble-shooting.
Material moving way:
"unwinding" --" web guide " -- pulling " --"1st coating (straight & reverse coating)"-- "drying (12m/3m)" --"edge positioning "--"1st cooling " --"2nd coating (straight & reverse coating)" --"drying (18m/3m)" --"edge positioning " --"pulling "--" storage "--" web guide " --"rewinding"
